Mini Type Film Blowing Machine

Mini Type Film Blowing Machine

Model
MINI MONO
·Compact size with lifting mechanism for flexible operation
·Film width 100–500mm, output up to 50 kg/h (LDPE)
·Screw and barrel in 38CrMoAlA nitrided alloy steel
·CE & ISO9001 certified
·37+ years manufacturing experience
Send Inquiry
Description
Technical Parameters

Zhejiang Zhuxin Machinery Co., Ltd. is one of the leading manufacturers and suppliers of mini type film blowing machine in China. With abundant experience, we warmly welcome you to buy durable mini type film blowing machine made in China here from our factory.







100–500mm

Film Width





HDPE 40 kg/h / LDPE 50 kg/h

Output





φ45

Screw Diameter





HDPE 0.01–0.10mm / LDPE 0.02–0.15mm

Film Thickness:

Product Overview

Mini Film Blowing Machine

The mini film blowing machine with lifting mechanism is a newly designed device. The lifting mechanism can adjust the machine height for more flexible and convenient operation, which improves production efficiency. Both the screw and barrel are made of 38CrMoAlA alloy steel that has undergone nitriding treatment, and the screw is also treated with hard alloy spraying, resulting in high hardness and good wear and corrosion resistance. The machine is suitable for blow molding LDPE, HDPE, and LLDPE film, widely used for supermarket flat pockets, vest bags, and garbage bags. Film width ranges from 100mm to 500mm, with thickness from 0.01mm (HDPE) up to 0.15mm (LDPE), and max output of 40kg/h for HDPE and 50kg/h for LDPE. With its small footprint and simple structure, this machine fits workshops with limited space and factories that want to start film production with a low initial investment.

img28193(001)











 Technical Specifications

Complete Technical Parameters

Detailed specifications for the SHXJ-6LINES automatic plastic bag making machine.

Mode

MINI-45
Suitable Material LDPE / HDPE / LLDPE
Film Width 100–500mm
Film Thickness (HD) 0.01–0.10mm
Film Thickness (LD) 0.02–0.15mm
Max Extrusion Output (HD) 40kg/h
Max Extrusion Output (LD 50kg/h
Screw Diameter φ45
Screw L/D Ratio 32:1
Die Size (HD) φ60
Die Size (LD) φ100
Roller Width 600mm
Effective Width 500mm

* Specifications are subject to change without prior notice. Custom configurations available upon request.











 Key Features

Core Function Highlights

Five key features that make the MINI-45 the preferred choice for small workshops and start-ups.

Small size, easy to move and install:

The machine is equipped with a PLC control system. Its operation is intuitive and easy to learn. Most operators can master it after just one day of training. This is a significant advantage, as many factory workers lack strong technical skills.

Lifting mechanism for flexible operation:

The newly designed lifting mechanism allows operators to adjust the machine height according to different working conditions. Film take-up and roll handling become more comfortable, which reduces operator fatigue during long shifts and improves production efficiency.

High production efficiency:

Despite its small size, the machine produces film quickly and continuously, up to 50kg/h for LDPE. For small factories producing flat pockets, vest bags, and garbage bags for local markets, this output level matches real daily demand without over-investment.

Easy to operate and maintain:

The structure is simple, so operators can pick it up quickly and daily maintenance is straightforward. Wear parts are easy to access, and maintenance can be done by the factory's own staff without calling a technician for every small issue.

Durable screw and barrel

Both the screw and barrel are made of 38CrMoAlA alloy steel with nitriding treatment, and the screw is additionally treated with hard alloy spraying. This gives high hardness and good wear and corrosion resistance, so the machine keeps stable extrusion even after long running hours on recycled or mixed materials.

















 Bag Types

Versatile Bag Production

Start small, cover the most common local bag film markets.



Supermarket Flat Pocket Film

0.01–0.10mm, 100–500mm width

Vest Bag Film

0.01–0.15mm, 100–500mm width

Garbage Bag Film

0.02–0.15mm, 100–500mm width











 Quality Assurance

Certified Quality You Can Trust

Every ZHUXIN machine undergoes rigorous quality control, backed by international certifications and decades of engineering expertise.

ZHUXIN machine











 FAQ

Frequently Asked Questions

Find answers to common questions about the CY-800ZD and our services.

Q: What is the turnover?

A: We have maintained steady growth year by year. Exact figures can be discussed privately.

Q:Do you have a showroom?

A: Yes, we have running machines in our factory for demonstration.

Q: Can you customize for clients?

A: Yes, we can customize as your need. We have R&D department; our engineers can adjust machine configuration based on your requirements.

Q: Do you have booth in shows?

A: Yes, we have booth in international exhibitions such as Chinaplas, InterPlas Thailand, and regional plastics shows in Africa, Middle East, and South America.
