CHARACTERISTIC
01 The forming template adopts symmetrical adjustable double- template structure (proprietary technology), so that users of different sizes of paper bags no longer need to change the template, which can effectively reduce the time of paper bag size adjustment and increase the machine capacity.
02 The special design greatly improves the bag-making range of the machine, which can meet the customer's demand of producing extra-large hand-held paper bags.
03 The electronic control system from Japan is adopted to ensure stable and high-speed operation
04 Material loading adopts hydraulic automatic lifting structure, with automatic tension control.
05 material loading adopts ARISE EPC system, reduce material alignment time.
PARAMETER
BAG MACHINE MODEL | ZXFD-180T | ZXFD-330T | ZXFD-460T |
Paper diameter | ≤1300mm | ≤1300mm | ≤1300mm |
Core inner diameter | Φ76mm | Φ76mm | Φ76mm |
Paper weight | 45-130g | 80-150g | 80-150g |
Paper bag width (with handle) | 120-180mm | 200-330mm | 250-400mm |
Paper bag width (without handle) | 80-180mm | 140-330mm | 220-460mm |
Paper tube length (With handle) | 191-330mm | 260-530mm | 280-500mm |
Paper tube length (Without handle) | 191-430mm | 260-430mm | 280-600mm |
Bottom width | 50-120mm | 60-180mm | 90-200mm |
Machine speed | 150pcs/min | 150pcs/min | 150pcs/min |
Total power | 32KW | 23/42KW | 34KW |
Machine weight (with handle) | 13000KG | 16000KG | 18000KG |
Machine weight (without handle) | 7000KG | 9000 | 10000KG |
Machine dimension(with handle) | 12×5×2.5 M | 11×2.6×1.8M | 15×5×2.5 M |
Machine dimension(without handle) | 12×5×2.5 M | 14×6×3 M | 15×5×2.5 M |
HANDLE MODEL | 114DH | 152DH | 152HD | 190HD |
Handle rope height(mm) | 102/115/ | 102/115/ | 102/115/ | 115/125/ |
Handle patch width | 45-50 mm | 45-50 mm | 45-50mm | 45-50mm |
Handle patch length | 114.3 mm | 114.3mm | 152.4 mm | 190.5 mm |
Handle rope diameter | Φ4-6mm | Φ4-6mm | Φ4-6mm | Φ4-6mm |
Dia. of handle patch paper roll | Φ1200mm | Φ1200mm | Φ1000mm | Φ1200mm |
Handle patch paper roll width | 90-100mm | 90-100mm | 90-100mm | 90-100mm |
Handle patch weight | 100-120g | 100-120g | 100-120g | 100-120g |
Photo |
|
|
|
|
